JACP-317800 CP-317/LIO-01 YASKAWA

Features Powered by SPEED7

Work memory [KB]: 8MB

Integrated: PROFINET IO controller

SPEED-Bus

Interface [RJ45]: PROFINET

Interface [RJ45]: Ethernet PG/OP communication

Interface [RS485]: MPI

Interface [RS485]: PROFIBUS master/slave, PtP: ASCII,

STX/ETX, 3964(R), USS master, Modbus master/slave

SD/MMC card slot with locking, up to 32 modules stackable,

programmable with WinPLC7, SIMATIC Manager and TIA Portal

Diagnostic interrupt no

Diagnostic functions yes

Diagnostics information read-out possible

Supply voltage display green LED

Group error display red SF LED

Channel error display none

Command processing times

Bit instructions, min. 0.01 µs

Word instruction, min. 0.01 µs

Double integer arithmetic, min. 0.01 µs

Floating-point arithmetic, min. 0.06 µs

Timers/Counters and their retentive characteristics

Number of S7 counters 2048

S7 counter remanence adjustable 0 up to 2048

S7 counter remanence adjustable C0 .. C7

Number of S7 times 2048

S7 times remanence adjustable 0 up to 2048

S7 times remanence adjustable not retentive

Data range and retentive characteristic

Number of flags 16384 Byte

Bit memories retentive characteristic adjustable adjustable 0 up to 16384

Bit memories retentive characteristic preset MB0 .. MB15

Number of data blocks 8190

Max. data blocks size 64 KB

Number range DBs 1 ... 8190

Max. local data size per execution level 3072 Byte

Max. local data size per block 3072 Byte

Blocks

Number of OBs 24

Maximum OB size 64 KB

Total number DBs, FBs, FCs -

Number of FBs 8191

Maximum FB size 64 KB

Number range FBs 0 ... 8190

Number of FCs 8191

Maximum FC size 64 KB

Number range FCs 0 ... 8190

Maximum nesting depth per priority class 16

Maximum nesting depth additional within an error OB 4

Time

Real-time clock buffered yes

Clock buffered period (min.) 6 w

Type of buffering Vanadium Rechargeable Lithium Battery

Load time for 50% buffering period 20 h

Load time for 100% buffering period 48 h

Accuracy (max. deviation per day) 10 s

Number of operating hours counter 8
