CP-317/AI-01 JACP-317803 YASKAWA

Type X3

Type of interface RS485

Connector Sub-D, 9-pin, female

Electrically isolated yes

MPI -

MP²I (MPI/RS232) -

DP master yes

DP slave yes

Point-to-point interface yes

5V DC Power supply max. 90mA, isolated

24V DC Power supply max. 100mA, non-isolated

Functionality RJ45 interfaces

Type X5

Type of interface Ethernet 10/100 MBit

Connector RJ45

Electrically isolated yes

PG/OP channel yes

Number of connections, max. 4

Productive connections -

Fieldbus -

Type X8

Type of interface Ethernet 10/100 MBit

Connector RJ45

Electrically isolated yes

PG/OP channel yes

Number of connections, max. 8

Productive connections yes

Fieldbus -

Point-to-point communication

PtP communication yes

Interface isolated yes

RS232 interface -

RS422 interface -

RS485 interface yes

Connector Sub-D, 9-pin, female

Transmission speed, min. 150 bit/s

Transmission speed, max. 115.5 kbit/s

Cable length, max. 500 m

Point-to-point protocol

ASCII protocol yes

STX/ETX protocol yes

3964(R) protocol yes

RK512 protocol -

USS master protocol yes

Modbus master protocol yes

Modbus slave protocol -

Special protocols -

Properties PROFINET I/O controller

Realtime Class -

Conformance Class PROFINET IO
