Failed Speed Signal Override

Circuits in the 2301A Speed Control constantly monitor the signal from the MPU.

Should this signal be below a minimum threshold the control sends a minimum

fuel signal to the actuator (maximum fuel signal on a reverse acting control).

Manual 82020 2301A Speed Control

Woodward 11

Before start-up of the prime mover, the speed signal is nonexistent, activating the

failed speed signal circuit. On units with cranking motors, the cranking speed is

usually sufficient to provide a speed signal, so an override contact is not needed

for starting. On some steam turbine systems, the Close for Override of Failed

Speed Signal contact must be closed to allow the actuator to open and provide

steam for starting.

The failed speed-signal override switch should be a momentary switch so the

failed-speed-sensor circuit will be enabled after start-up.

Idle/Rated Ramp Contact

Connect a single-pole, single throw switch to terminal 5 as shown on the

appropriate plant-wiring diagram. Close the contact for rated, open for idle. Oil

pressure is often used to close this contact. When closed, 10 to 40 Vdc is applied

to terminal 5, and the prime mover can be operated at a speed higher than idle.

When the contact is open, the voltage is removed from terminal 5, and the prime

mover's speed decelerates to idle. The ramp rate applies only to the acceleration

mode. When the ramp time potentiometer is full cw the ramp time from idle to

rated is 22 ±4 seconds. When the ramp time potentiometer is fully ccw (be

careful not to overtorque the pot), the ramp rate is less than 1 second from

idle to rated.

The ramp time from rated to idle is always less than 1 second, regardless of the

setting of the ramp-time potentiometer.

Actuator Output

The actuator wires connect to terminals 9 (+) and 10 (–). Use shielded wires with

the shield connected to the grounded post on the panel. Do not connect the

shield to the actuator or to any other point. The shield must have continuity the

entire distance to the actuator and must be insulated from all other conductors.

Some 2301As may be used to operate prime movers in tandem by wiring the two

actuators in series as shown in detail A of the wiring diagram. Tandem operation

with a single 2301A control requires that the two engines provide identical power

response to identical current signals to each of the actuators.
