Power supply output must be low impedance (for example, directly from

batteries). DO NOT power low-voltage versions of the control from high-voltage

sources with resistors and zener diodes in series with the control power input.

The 2301A control contains a switching power supply which requires a current

surge to start properly.

To prevent damage to the control, do not power low-voltage versions

of the control from high-voltage sources.

High and low voltage models of 2301A Speed Controls are available. Low

voltage models require a supply of 10 to 40 Vdc, 12 W. High voltage models

require a supply of 88 to 120 Vac or 90 to 150 Vdc., 12 W. The ac supply may be

50 to 400 Hz.

If a battery is used for operating power, an alternator or other battery charging

device is necessary to maintain a stable supply voltage.

To prevent damage to the control, make sure that the alternator or

other battery-charging device is not connected to the control when

the battery is disconnected from the control.

Location Considerations

Consider these requirements when selecting the mounting location:

· Adequate ventilation for cooling

· Space for servicing and repair

· Protection from direct exposure to water or to a condensation-prone

environment

· Protection from high-voltage or high-current devices, or devices which

produce electromagnetic interference

· Protection from excessive vibration

· An ambient operating temperature range of –40 to +85 °C (–40 to +185 °F)

Do not mount the control on the engine.

Electrical Connections

External wiring connections and shielding requirements for a typical control

installation are shown in the plant wiring diagram, Figures 2-4 and 2-5. These

wiring connections and shielding requirements are explained in the balance of

this section.
