9905-003 WOODWARD

Low speed is not

regulated by LOW

IDLE SPEED

potentiometer.

NOTE

On carbureted prime movers, the

minimum fuel stop rpm setting will

vary with prime mover

temperature. An improper cold

setting may interfere with the Low

Idle Speed Setting when the prime

mover is hot.

The Low Idle Speed setting may be below the minfuel position of the actuator or prime-mover fuel

stop. In this case, the output voltage to the actuator

will be zero (maximum for reverse acting controls).

The engine will be maintained at the min-fuel

position by the actuator or the prime mover min-fuel

stop. The conditions indicate that the min-fuel

position should be decreased by linkage

adjustment (diesel) or low-idle set screw (gas

engine), or the LOW IDLE SPEED setting should

be raised. If this does not correct the problem, the

2301A control may be faulty.

LOW IDLE SPEED potentiometer. If adjustment of the LOW IDLE SPEED

potentiometer causes erratic behavior, replace the

control.

Prime mover does

not decelerate when

Close for Rated

contact is open.

Faulty Close for Rated contact or

wiring.

The voltage from terminal 5 (–) to 2 (+) on low

voltage controls or 5 (–) to 6 (+) on high voltage

controls must be less than 2 volts. Replace the

contact or wiring as necessary.

LOW IDLE SPEED set fully cw

(be careful not to overtorque

the pot).

Turn LOW IDLE SPEED setting ccw with terminal 5

open.

2301A ramp circuitry.

WARNING

The speed-setting controls

have sufficient range to

override the ramp and bring the

prime-mover speed up to rated

while still in the low-idle mode

(because of control or

switching defect). A Close for

Rated contact that is

intermittent may cause the

prime mover to overspeed if the

RATED SPEED setting is

adjusted for rated speed with

terminal 5 open.

A faulty Close for Rated contact may remain in the

accelerate position with the contact open.

If the Close for Rated contact is operative, loss of

idle control may be due to a faulty circuit.

In general, adjustment of LOW IDLE SPEED will

vary the speed of the prime mover with the Close

for Rated contact in the decelerate (open) position.

Adjustment of LOW IDLE SPEED should not affect

prime mover speed when the Close of Rated

contact is closed.

Prime mover will not

stabilize at rated noload speed. The

instability may occur

at no load or it may

vary with load.

Control may be

erratic.

2301A Speed Control. Adjust GAIN, RESET, and ACTUATOR

COMPENSATION as described in "Adjust for

Stable Operation" and "Dynamic Adjustment" in

Chapter 3.

Speed setting controls. If adjustment of external speed trim causes

instability, check potentiometer with ohmmeter for

erratic behavior. (Turn power off). Use nonlubricating electrical cleaner if necessary. If internal

potentiometer is faulty, replace control.

Improper linkage adjustment. Make sure the actuator moves about 2/3 of its

travel from no load to full load. Be sure linkage

provides a proportional change in power for every

change in actuator terminal-shaft position. Refer to

the actuator manual for more detailed linkage

instructions.

Necessary wires not properly

shielded.

Electrical noise, caused by wiring carrying an ac

voltage or stray magnetic fields, can be picked up

by improperly shielded wire.

Noise will cause instability. See "Shielding" in

Chapter 3.
