The RATED SPEED potentiometer, adjusted so the converter-speed voltage

and the reference-speed voltage are equal at the desired operating speed.

· The LOW IDLE potentiometer, adjusted so the reference voltage is correct

for the desired idle speed.

· The START FUEL LIMIT potentiometer to provide a means of limiting the

fuel-rack position when starting diesel engines. Adjustment of the

potentiometer sets the maximum actuator position from no speed until the

speed control calls for a fuel setting lower than the setting of the start-fuel

limit. The limit is automatically placed in the circuit whenever the speed

monitor input declines below the Failed Speed Signal level. Setting the Start

Fuel Limit potentiometer full cw will raise the limit above the maximum fuel

position, making the limit non-effective.

· RESET, GAIN, and ACTUATOR COMPENSATION potentiometers adjust

the control amplifier to accommodate various types of prime-movers. Reset

adjustment affects reaction time when recovering after a sudden load

change. The magnitude of the speed change resulting from a sudden change

in load is controlled by adjusting the Gain potentiometer. Actuator

Compensation compensates for the time the actuator and prime-mover

system take to react to signals from the control.

· The RAMP TIME potentiometer sets the time required for the prime mover to

accelerate from idle to rated speed.

Droop and Speed Trim settings change at 10% of the existing

reference per volt. The Auxiliary input causes a 3% speed change per

volt. The Synchronizer input causes a 0.666% change of reference

speed per volt.

Actuator Circuit Protection

The speed control is protected from shorts or overloads in the actuator circuit at

terminals 9 and 10 by an automatic circuit breaker. The circuit breaker will reset

automatically after the short or overload is corrected and the control has a few

minutes to cool down.

Reverse Acting Controls

The reverse-acting 2301A Speed Control and its actuator are designed so that

zero voltage to the actuator corresponds to maximum fuel to the prime mover.

The actuator usually used with a reverse-acting control has a mechanical

governing mechanism included (see Figure 4-3). The speed setting of this

mechanical governor is slightly higher than the speed setting of the 2301A.

Should the electronics fail, the actuator will try to go to maximum fuel but will be

stopped when it gets to the speed setting of the mechanical governor, providing

continued operation of the prime mover, although at a speed which is slightly

higher than the electronic control speed reference.
