8271-464 WOODWARD

Speed Adjusting Motor and Manual Speed Adjustment

Figure 7-5

The 24 Vdc speed adjusting motor is installed on the governor cover, and rotates

a speed adjusting screw to adjust the position of the governor speed adjusting

lever.

Figure 7-5. Speed Adjusting Motor and Manual Speed Adjustment

If the speed adjusting motor has been allowed to run after low speed

setting has been reached, it may take a period of time for the speed

adjusting screw to turn in and make contact with the speed adjusting

lever when an increase in speed setting is required.

Speed can also be increased or decreased by the slotted speed setting

adjustment located on the front of the governor. Turn the speed setting

adjustment clockwise to increase speed setting, and counterclockwise to

decrease speed setting. The high and low speed stops will limit speed

adjustments.

Load Limit Assembly

The slotted load limit adjustment is located on front of the governor cover, and is

set manually to a position of 0 to 10 on the load limit dial. Turning the load limit

adjustment clockwise rotates an eccentric cam, limiting fuel at a higher level.

Turning the adjustment counter-clockwise limits fuel at a lower level.
