To prevent damage to a control system that uses an alternator or

battery-charging device, make sure the charging device is turned off

before disconnecting the battery from the system.

Electrostatic Discharge Awareness

Electrostatic

Precautions

Electronic controls contain static-sensitive parts. Observe the

following precautions to prevent damage to these parts:

· Discharge body static before handling the control (with power to

the control turned off, contact a grounded surface and maintain

contact while handling the control).

· Avoid all plastic, vinyl, and Styrofoam (except antistatic versions)

around printed circuit boards.

· Do not touch the components or conductors on a printed circuit

board with your hands or with conductive devices.

To prevent damage to electronic components caused by improper

handling, read and observe the precautions in Woodward manual

82715, Guide for Handling and Protection of Electronic Controls,

Printed Circuit Boards, and Modules.

Follow these precautions when working with or near the control.

1. Avoid the build-up of static electricity on your body by not wearing clothing

made of synthetic materials. Wear cotton or cotton-blend materials as much

as possible because these do not store static electric charges as much as

synthetics.

2. Do not remove the printed circuit board (PCB) from the control cabinet

unless absolutely necessary. If you must remove the PCB from the control

cabinet, follow these precautions:

· Do not touch any part of the PCB except the edges.

· Do not touch the electrical conductors, the connectors, or the

components with conductive devices or with your hands.

· When replacing a PCB, keep the new PCB in the plastic antistatic

protective bag it comes in until you are ready to install it. Immediately

after removing the old PCB from the control cabinet, place it in the

antistatic protective bag.
