Governor faults are usually revealed as speed variations of the prime mover,

however, it does not necessarily follow that all speed variations indicate governor

faults. Troubleshoot the governor to localize a problem before attempting

disassembly and repair.

Use the following Troubleshooting Diagram to troubleshoot your governor. See

Chapter 6, Governor Calibration, or refer to the engine manufacturer’s

specifications for engine calibration.

Be prepared to make an emergency shutdown when starting the

engine, turbine, or other type of prime mover, to protect against

runaway or overspeed with possible personal injury, loss of life, or

property damage.

Problem Question Procedure

Engine cranks,

but governor

output shaft

doesn’t move

from minimum

position.

With manual

assistance, can

the governor

output shaft be

easily moved

towards

maximum while

cranking?

YES—

1. Is governor filled with oil?

2. Is the rotation of the pump set correctly?

3. Have you cranked the engine for at least 10 seconds to allow the

governor time to develop pressure?

4. Is the drive shaft connected?

5. Is the oil viscosity greater than 50 SUS?

6. Is the cranking speed too low?

NO—

1. Are any shutdown devices activated or incorrectly adjusted?

2. Is speed setting above cranking speed?

3. Is linkage free from excessive friction?

4. Is load limit set at zero?

5. If fuel limiter is used, is it correctly adjusted?

Governor opens

fuel, but is slow

and sluggish.

 1. Are shutdowns properly adjusted?

2. Is the governor oil viscosity less than 50 SUS, or above 3000

SUS?

3. Is the need valve closed too far?

4. Is linkage to the engine free?

Governor opens

fuel, but only part

way.

 1. Is load limited adjusted properly, and set out of the way?

2. Is there adequate manifold pressure? [applies to fuel limit type

governors]

3. Is fuel stop on engine adjusted properly?

4. Is fuel stop in governor set properly?

5. Is fuel linkage free?

Governor opens

fuel and prime

mover starts, but

trips out on

overspeed.

 1. Is the linkage sticky?

2. Is the linkage properly adjusted?

3. Is the overspeed trip set properly?

4. Is the needle valve closed too far?

5. Is the governor speed setting too high?

System oscillates

and is unstable.

Check the following:

1. Is droop properly set?

2. Is the needle valve correctly adjusted?

3. Is linkage sticky or worn?
