5464-348 WOODWARD

Each Woodward Electrically Powered Governor (EPG) system includes three

basic parts:

· A magnetic pickup (MPU) which senses engine speed from an enginedriven gear.

· A speed control which receives the speed signal from the MPU, compares it

to a reference signal, and generates a control signal which the control sends

to the actuator.

· An actuator which receives the signal from the control and positions its

output shaft according to this signal. The output shaft is linked to the fuel

control.

There are two EPG models:

· The isochronous speed control, which is available with start-fuel limit or dual

dynamics;

· The droop speed control, which includes a load sensor and provides droop

control for generator sets.

Different actuator sizes are available for different work output requirements.

Models are available for either 12 or 24 volt systems.

Associated Publications

Manual Title

82313 Generator Load Sensor

25070 Electronic Control Installation Guide

82510 Magnetic Pickups & Proximity Switches for Electronic Controls

82493 Isochronous EPG

82327 EPG with Droop

82476 Ramp Generator

Product

Spec. Title

04106 EPG Electrically Powered Governors

82314 Generator Load Sensor
