1825-97 WOODWARD

Speed Trim

A speed trim potentiometer or digital reference unit is connected to terminals 11

and 12. Use a high quality 100 W, 10-turn potentiometer (Woodward part 1657-

537 or equivalent) to provide about ±5% speed adjustment. Terminals 11 and 12

must be jumpered if the speed trim potentiometer or digital reference unit is not

used. The 2301A Speed Control will have a jumper installed in the factory and

this must be removed if a speed-trim device is used.

Droop Potentiometer

A 2K potentiometer may be connected to provide a maximum of about 8% droop.

Connect the potentiometer (ccw) to terminal 15, (cw) to terminal 14, and wiper to

terminal 13. If droop is not desired make no connections to terminals 13 and 14.

Switch Options

Minimum Fuel Contact

The minimum-fuel contact between terminals 2 and 3 on the low-power models

and 3 and 6 on the high-power models is intended as an optional means for a

normal shutdown of the prime mover. The contact is connected as shown on the

plant wiring diagram for the particular control. If a minimum fuel contact is not

used, the terminals must be permanently jumpered.

Do NOT use the minimum-fuel contact as a part of any emergency

stop sequence. The emergency may be caused by a governor

malfunction which would also cause a malfunction of the minimumfuel feature. Use of the minimum-fuel contact for an emergency stop

sequence could cause overspeed of the prime mover and mechanical

damage and personal injury, including death.
