WAGO 767-4801 SPEEDWAY DIGITAL INPUT MODULE

WAGO 767-4801 SPEEDWAY DIGITAL INPUT MODULE

PanelView Plus 6 - 700…1500 Terminals

The PanelView Plus 6 - 700…1500 terminals use modular components that

allow for flexible configuration, installation, and upgrades. Factory-assembled

terminals, with a display module and logic module, are available as one catalog

number or as separate components for field installation. Optional

communication modules can be ordered for additional network

communication.

The field-replaceable 6.5, 10.4, 12.1, and 15.1-in. flat-panel color displays come

with keypad, touch screen, or keypad/touch-screen input. Other display

options are available to meet more stringent environmental conditions:

• High-bright display module for outdoor applications

• Conformal-coated displays

• Marine-certified displays and logic modules

• Displays with built-in antiglare overlays

For a complete listing of catalog number selections, refer to the Visualization Solutions Selection Guide, publication

VIEW-SG001.

The high-performance logic module runs the Windows CE 6.0 operating system, that allows you to run HMI

applications with the ability to also access the desktop. For users with more complex application requirements, the

platform and logic module can be ordered with optional, extended features and file viewers.

Table 3 - Logic Module
