MDD112D-N-030-N2M-130PA2 Rexroth

MDD112D-N-030-N2M-130PA2  Rexroth Industrial control module spot

Tab. 5-17: Definition of Performance Profiles, Infeeding Supply Units and Con‐

verters

Operation with standard motors

General information

Selecting standard motors The tables below show the nominal powers Pnenn of standard motors which

can be operated at the respective drive controller. The following conditions

apply to the data in the tables:

● Motor design:

4-pole standard motor (2 pole pairs) with rated voltage 3 AC 400 V,

50 Hz at mains voltage ULN ≥ 3 AC 400 V or

4-pole standard motor (2 pole pairs) with rated voltage 3 AC 460 V,

60 Hz at mains voltage ULN ≥ 3 AC 460 V

● Assigned mains choke is used

● Operation at minimum switching frequency fs= fs

 (min.)

● Rotary field at output with fout>fout_still

● Ambient temperature Ta≤Ta_work

● Overload ratio K = PDC_peak / PDC_base according to performance profile

"UEL_P_e"

● Type of mains connection: Individual Supply

When choosing standard motors for inverters, select an appropri‐

ate supply unit. Observe the performance data PDC_peak and

PDC_base in the performance profile "UEL_P_e" o
