) Also depending on firmware and control section; see parame‐

ter description "P-0-0001, Switching frequency of the power

output stage"; see "P-0-4058, Amplifier type data"; for supply

units the switching frequency is 4.2 kHz

2) 3) Guide value, see following note

4) See following note regarding output current reduction

5) 6) 7) 8) See parameter description "P-0-0556, Config word of axis con‐

troller", load-dependent reduction of switching frequency fs

Tab. 5-13: HCS - Power section data - inverter

Guide value "Rise of voltage at output"

Observe that the voltage load at the motor is almost independent

of the power section used.

Especially when using standard motors, make sure that they com‐

ply with the occurring voltage load.

Observe the information on third-party motors at drive controllers

(see documentation "Rexroth IndraDrive Drive Systems With

HMV01/02 HMS01/02, HMD01, HCS02/03", index entry "Thirdparty motors → On drive controllers").
