0608830109 SE110 Rexroth

0608830109 SE110  Industrial control module spot

Chapter Changes

Introduction Reference documentations updated

Rexroth IndraDrive Con‐trol Sections

CSH01.3C (ADVANCED) control sections included

Type codes for CDB and CSH control sections updated

Optional Modules forControl SectionsCommunications:

● ET (Multi-Ethernet) included

● CD (DeviceNet/CANopen with D‑SUB connection):

Pin assignment X61 corrected

● S3 (SERCOS III): Recommended cable type and com‐

patibility correctedI/O extensions:

Optional module AN: Description of pin assignment adjusted

Safety technology:

● L2 (Safe Torque Off) included

● S2 (Safe Motion) included

● L1 (starting lockout): Note on commissioning added

● S1 (Safety technology I/O): Note on commissioningadded

Comfort control panel VCP01 included

Information on optional MultiMediaCard PFM02.1 included

Technical Data - Func‐tions

X26, Engineering interface: Recommended cable type and

compatibility correctedFig.1-1: Changes

1.1.2 Reference Documentations

Drive Systems, System ComponentsTitleRexroth IndraDrive …

Kind of documentation Document typecode1)DOK-INDRV*-…

Drive Systems With HMV01/02HMS01/02, HMD01, HCS02/03

Project Planning Manual SYSTEM*****-PRxx-EN-P 309636

Mi Drive Systems Project Planning Manual KCU+KSM****-PRxx-EN-P 320924

Supply Units, Power Sections

HMV, HMS, HMD, HCS02, HCS03

Project Planning Manual HMV-S-D+HCS-PRxx-EN-P 318790

Drive controllersControl Sections CSB01, CSH01,CDB01

Project Planning Manual CSH********-PRxx-EN-P 295012

DOK-INDRV*-CSH********-PR08-EN-P

Rexroth IndraDrive Drive Controllers - Control Sections CSB01, CSH01, CDB01

Bosch Rexroth AG 7/195IntroductionCourtesy of CMA/Flodyne/Hydradyne ▪ Motion Con
