Brand： P+F Model number：KG30-R/Ex
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin:
Price: Please contact us Product weight：0.22kg
hipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Servce: Professional Sales provides 24 hours /7 days online service
KG30-R/Ex P+F Industrial control module spot
Application and general description
The GT300 Pressure Transmitter is a generalpurpose transmitter for use in engine rooms and
other similar applications. The transmitter is
available as gauge and sealed gauge. With pressure
ranges up to 100 bar, and a 2-wire connection, 4 to
20 mA ouput signal.
Mechanical design
The transmitter consists of a sensing element
together with an electronic unit encapsulated in the
sensor body. Pressure connection is made via
ISO228-G1/2A or ISO228-G1/4A at the lower end,
and electrical connection is made via a DIN
connector at the upper end of the transmitter. The
body is made of acid resistant steel. See Fig. 2.
Pressure sensing capsule
The pressure transmitter is built around a dry,
robust sensor element, made of ceramic, with
internal strain gauge Wheatstone-bridge as a
converting element between pressure and electrical
signal. The signal given by this strain gauge is then
digitized and stored together with known applied
pressure and temperature. All this together forms a
unique tabular for each sensor, which is kept in
sensor memory for the sensor’s lifetime. This
digital compensation gives a possibility for
linearization and temperature
compensation of each transmitter uniquely, based
on each element’s character. This enables a much
higher accuracy and temperature stability than with
former analogue sensors.
As the 96 % alumina membrane is resistant to most
chemicals, the process medium is in direct contact
with the measuring membrane, thus there is no
need for costly de-coupling in the form of a filling
liquid and second membrane. A filling liquid and a
seco
