Brand： National Instruments Model number：PXIe-5693
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
hipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
PXIe-5693 National Instruments Spare parts in stock
Table 2. AO Absolute Accuracy
Nominal
Range
Positive
Full Scale
Nominal
Range
Negative
Full Scale
Residual
Gain Error
(ppm of
Reading)
Gain
Tempco
(ppm/°C)
Residual
Offset
Error (ppm
of Range)
Offset
Tempco
(ppm of
Range/°C)
Absolute
Accuracy
at Full
Scale (μV)
10 -10 90 10 40 5 3,230
Reference tempco 5 ppm/°C
INL error 128 ppm of range
AO Absolute Accuracy Equation
AbsoluteAccuracy = OutputValue · (GainError) + Range · (OffsetError)
GainError = ResidualGainError + GainTempco · (TempChangeFromLastInternalCal) +
ReferenceTempco · (TempChangeFromLastExternalCal)
OffsetError = ResidualOffsetError + AOOffsetTempco ·
(TempChangeFromLastInternalCal) + INLError
Digital I/O/PFI
Static Characteristics
Number of channels 24 total, 8 (P0.<0..7>),
16 (PFI <0..7>/P1, PFI <8..15>/P2)
Ground reference D GND
Direction control Each terminal individually programmable as
input or output
Pull-down resistor 50 kΩ typical, 20 kΩ minimum
Input voltage protection ±20 V on up to two pins2
Waveform Characteristics (Port 0 Only)
Terminals used Port 0 (P0.<0..7>)
Port/sample size Up to 8 bits
Waveform generation (DO) FIFO 2,047 samples
Waveform acquisition (DI) FIFO 2,047 samples
PXI-6120
PXIE-6366
PXI-6289
PXIE-7961R
PCI-8517
PXI-2545
PXI-7952R
PXI-6723
PCI-6031E
PXIE-7962R
CDAQ-9171
PXIE-1095
PCI-4474
PXI-6115
PXI-2596
PXI-6515
PCIE-8381
PXIE-1082
PXIE-8135
PXIE-7976R
NI-5791
PXI-6224
CDAQ-9181
PXI-2597
PCI-6224
PXI-8331
NI-9250
PXI-6238
PXIE-6358
