PXI-2596 National Instruments

PXI-2596 National Instruments Physical Characteristics

Brand： National Instruments

Model number：PXI-2596

Colour：new

Warranty: 12 months

Lead Time：3-day working day

Country of origin: USA

Price: Please contact us

Product weight：0.155kg

hipping Port: China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

PXI-2596 National Instruments Multiplexer Switch Module

Inquire Now Next Product

Additional Information:

NI recommends against switching active RF signals. As a relay actuates, the

channel is momentarily unterminated. Some RF sources can be damaged by

reflections if their outputs are not properly terminated. Refer to your RF source

documentation for more information.

PXI-2596 National Instruments

Random vibration

Operating 5 Hz to 500 Hz, 0.31 grms (Tested in

accordance with IEC 60068-2-64.)

Nonoperating 5 Hz to 500 Hz, 2.46 grms (Tested in

accordance with IEC 60068-2-64. Test profile

exceeds the requirements of MIL-PRF-28800F,

Class 3.)

Compliance and Certifications

Safety

This product is designed to meet the requirements of the following electrical equipment safety

standards for measurement, control, and laboratory use:

• IEC 61010-1, EN 61010-1

• UL 61010-1, CSA 61010-1

Note For UL and other safety certifications, refer to the product label or the Online

Product Certification section.

Electromagnetic Compatibility

This product meets the requirements of the following EMC standards for electrical equipment

for measurement, control, and laboratory use:

• EN 61326-1 (IEC 61326-1): Class A emissions; Basic immunity

• EN 55011 (CISPR 11): Group 1, Class A emissions

• AS/NZS CISPR 11: Group 1, Class A emissions

• FCC 47 CFR Part 15B: Class A emissions

• ICES-001: Class A emissions

Note In the United States (per FCC 47 CFR), Class A equipment is intended for

use in commercial, light-industrial, and heavy-industrial locations. In Europe,

Canada, Australia, and New Zealand (per CISPR 11), Class A equipment is intended

for use only in heavy-industrial locations.

Note Group 1 equipment (per CISPR 11) is any industrial, scientific, or medical

equipment that does not intentionally generate radio frequency energy for the

treatment of material or inspection/analysis purposes.

Note For EMC declarations and certifications, refer to the Online Product

Certification section.
