Brand： National Instruments Model number：PXI-2575
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
hipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
PXI-2575 National Instruments Spare parts in stock
Dimensions
PCI printed circuit board 10.6 cm × 15.5 cm (4.2 in. × 6.1 in.)
PXI printed circuit board Standard 3U PXI
USB Screw Terminal enclosure
(includes connectors)
26.67 cm × 17.09 cm × 4.45 cm
(10.5 in. × 6.73 in. × 1.75 in.)
USB Mass Termination
enclosure (includes connectors)
18.8 cm × 17.09 cm × 4.45 cm
(7.4 in. × 6.73 in. × 1.75 in.)
USB OEM Refer to the NI USB-622x/625x/628x OEM
User Guide
Weight
PCI 103 g (3.6 oz)
PXI 174 g (6.1 oz)
USB Screw Terminal 1.24 kg (2 lb 11 oz)
USB Mass Termination 907 g (2 lb)
USB OEM 162 g (5.7 oz)
I/O connectors
PCI/PXI 2 68-pin VHDCI
USB Screw Terminal 128 screw terminals
USB Mass Termination 2 68-pin SCSI
USB Screw Terminal/BNC screw terminal
wiring
16 to 28 AWG Maximum Working Voltage
Maximum working voltage refers to the signal voltage plus the common-mode voltage.
Channel-to-earth 11 V, Measurement Category I
Measurement Category I is for measurements performed on circuits not directly connected to
the electrical distribution system referred to as MAINS voltage. MAINS is a hazardous live
electrical supply system that powers equipment. This category is for measurements of voltages
from specially protected secondary circuits. Such voltage measurements include signal levels,
special equipment, limited-energy parts of equipment, circuits powered by regulated lowvoltage sources, and electronics.
Caution Do not use for measurements within Categories II, III, or IV.
Note Measurement Categories CAT I and CAT O (Other) are equivalent. These test
and measurement circuits are not intended for direct connection to the MAINS
building installations of Measurement Categories CAT II, CAT III, or CAT IV.
