Brand： National Instruments Model number：PXI-2570
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
hipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
PXI-2570 National Instruments Spare parts in stock
Table 2. AO Absolute Accuracy
Nominal
Range
Positive
Full Scale
Nominal
Range
Negative
Full Scale
Residual
Gain Error
(ppm of
Reading)
Gain
Tempco
(ppm/°C)
Residual
Offset
Error (ppm
of Range)
Offset
Tempco
(ppm of
Range/°C)
Absolute
Accuracy
at Full
Scale (μV)
10 -10 90 10 40 5 3,230
Reference tempco 5 ppm/°C
INL error 128 ppm of range
AO Absolute Accuracy Equation
AbsoluteAccuracy = OutputValue · (GainError) + Range · (OffsetError)
GainError = ResidualGainError + GainTempco · (TempChangeFromLastInternalCal) +
ReferenceTempco · (TempChangeFromLastExternalCal)
OffsetError = ResidualOffsetError + AOOffsetTempco ·
(TempChangeFromLastInternalCal) + INLError
Digital I/O/PFI
Static Characteristics
Number of channels 24 total, 8 (P0.<0..7>),
16 (PFI <0..7>/P1, PFI <8..15>/P2)
Ground reference D GND
Direction control Each terminal individually programmable as
input or output
Pull-down resistor 50 kΩ typical, 20 kΩ minimum
Input voltage protection ±20 V on up to two pins2
Waveform Characteristics (Port 0 Only)
Terminals used Port 0 (P0.<0..7>)
Port/sample size Up to 8 bits
Waveform generation (DO) FIFO 2,047 samples
Waveform acquisition (DI) FIFO 2,047 samples
