PXI-2569  National Instruments Spare parts in stock

PXI-2569 National Instruments Spare parts in stock

Brand: National Instruments     Model number:PXI-2569

Colour:new                  Warranty: 12 months

Lead Time:3-day working day   Country of origin: USA

Price: Please contact us         Product weight:0.22kg

hipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

PXI-2569  National Instruments Spare parts in stock

SCXI-1162HV   National Instruments    Industrial control module spot

Number of channels 40 differential or 80 single ended

ADC resolution 16 bits

DNL No missing codes guaranteed

INL Refer to the AI Absolute Accuracy section

Sample rate

Single channel maximum 250 kS/s

Multichannel maximum (aggregate) 250 kS/s

Minimum No minimum

Timing accuracy 50 ppm of sample rate

Timing resolution 50 ns

Input coupling DC

Input range ±0.2 V, ±1 V, ±5 V, ±10 V

Maximum working voltage for analog

inputs (signal + common mode)

±11 V of AI GND

CMRR (DC to 60 Hz) 92 dB

Input impedance

Device on

AI+ to AI GND >10 GΩ in parallel with 100 pF

AI- to AI GND >10 GΩ in parallel with 100 pF                                                                                                                                                                   Device off

AI+ to AI GND 820 Ω

AI- to AI GND 820 Ω

Input bias current ±100 pA

Crosstalk (at 100 kHz)

Adjacent channels -75 dB

Non-adjacent channels -90 dB1

Small signal bandwidth (-3 dB) 700 kHz

Input FIFO size 4,095 samples

Scan list memory 4,095 entries

Data transfers

PCI/PXI DMA (scatter-gather), interrupts,

programmed I/O

USB USB Signal Stream, programmed I/O

Overvoltage protection for all analog input and sense channels

Device on ±25 V for up to two AI pins

Device off ±15 V for up to two AI pins

Input current during overvoltage condition ±20 mA maximum/AI pin

Settling Time for Multichannel Measurements

Accuracy, full-scale step, all ranges

±90 ppm of step (±6 LSB) 4 μs convert interval

±30 ppm of step (±2 LSB) 5 μs convert interval

±15 ppm of step (±1 LSB) 7 μs convert interval



PXI-6120

PXIE-6366

PXI-6289

PXIE-7961R

PCI-8517

PXI-2545

PXI-7952R

PXI-6723

PCI-6031E

PXIE-7962R

CDAQ-9171

PXIE-1095

PCI-4474

PXI-6115

PXI-2596

PXI-6515

PCIE-8381

PXIE-1082

PXIE-8135

PXIE-7976R

NI-5791

PXI-6224

CDAQ-9181

PXI-2597

PCI-6224

PXI-8331

NI-9250

PXI-6238

PXIE-6358
