Brand： National Instruments Model number：PXI-2503
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
hipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
PXI-2503 National Instruments Spare parts in stock
Internal base clocks 80 MHz, 20 MHz, 0.1 MHz
External base clock frequency 0 MHz to 20 MHz
Base clock accuracy 50 ppm
Inputs Gate, Source, HW_Arm, Aux, A, B, Z,
Up_Down
Routing options for inputs Any PFI, RTSI, PXI_TRIG, PXI_STAR,
analog trigger, many internal signals
FIFO 2 samples
Data transfers
PCI/PXI Dedicated scatter-gather DMA controller for
each counter/timer; interrupts, programmed I/O
USB USB Signal Stream, programmed I/O
Frequency Generator
Number of channels 1
Base clocks 10 MHz, 100 kHz
Divisors 1 to 16
Base clock accuracy 50 ppm
Output can be available on any output PFI or RTSI terminal.
Phase-Locked Loop (PLL)
Note PCI/PXI devices only.
Number of PLLs 1
Reference signal PXI_STAR, PXI_CLK10, RTSI <0..7>
Output of PLL 80 MHz Timebase; other signals derived from
80 MHz Timebase including 20 MHz and
100 kHz Timebases
External Digital Triggers
Source Any PFI, RTSI, PXI_TRIG, PXI_STAR
Polarity Software-selectable for most signals
