NI PCI-6225  Card stock  ing module

NI PCI-6225 Card stock ing module

Brand:NI     Model number:NI PCI-6225

Colour:new                  Warranty: 12 months

Lead Time:3-day working day   Country of origin: USA

Price: Please contact us         Product weight:0.22kg

hipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

NI PCI-6225  Card stock  ing module
NI PCI-6225  Card stock  ing module

 output function Start Trigger, Pause Trigger, Sample Clock,

Sample Clock Timebase

Counter/timer function Gate, Source, HW_Arm, Aux, A, B, Z,

Up_Down

Digital waveform generation (DO)

function

Sample Clock

Digital waveform acquisition (DI)

function

Sample Clock

Device-to-Device Trigger Bus

PCI RTSI <0..7>4

PXI PXI_TRIG <0..7>, PXI_STAR

USB source None

Output selections 10 MHz Clock, frequency generator output,

many internal signals

Debounce filter settings 125 ns, 6.425 μs, 2.56 ms, disable; high and

low transitions; selectable per input

Bus Interface

PCI/PXI 3.3 V or 5 V signal environment

USB USB 2.0 Hi-Speed or full-speed5, 6

DMA channels (PCI/PXI) 6, can be used for analog input, analog output,

digital input, digital output, counter/timer 0,

counter/timer 1

USB Signal Stream 4, can be used for analog input, analog output,

counter/timer 0, counter/timer 1

The PXI device can be installed in PXI Express hybrid slots. It cannot be used to control SCXI

in PXI/SCXI combo chassis.

4

In other sections of this document, RTSI refers to RTSI <0..7> for the PCI devices or

PXI_TRIG <0..7> for PXI devices.

5

If you are using an USB M Series device in full-speed mode, device performance will be lower and

you will not be able to achieve maximum sample/update rates.

6 Operating on a full-speed bus may result in lower performance.
