Characteristics describe values that are relevant to the use of the model under stated operating
conditions but are not covered by the model warranty.
• Typical specifications describe the expected performance met by a majority of the
models.
• Nominal specifications describe parameters and attributes that may be useful in operation.
Specifications are Typical unless otherwise noted.
CDAQ-9188 NI Specifications are Typical
Brand： National Instruments Model number：CDAQ-9188
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.920kg
hipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
CDAQ-9188 NI Controller module Brand new
Note When parallel modules in a digital task are in slots 1 through 4, FIFO is
2,047 samples per slot for all slots. When any parallel module in a digital task is in
slots 5 through 8, FIFO is 1,023 samples per slot for all eight slots.
Digital input sample clock frequency
Streaming to application memory System-dependent
Finite 0 MHz to 10 MHz
Digital output sample clock frequency
Streaming from application memory System-dependent
Regeneration from FIFO 0 MHz to 10 MHz
Finite 0 MHz to 10 MHz
Timing accuracy 50 ppm
General-Purpose Counters/Timers
Number of counters/timers 4
Resolution 32 bits
Counter measurements Edge counting, pulse, semi-period, period,
two-edge separation, pulse width
Position measurements X1, X2, X4 quadrature encoding with
Channel Z reloading; two-pulse encoding
Output applications Pulse, pulse train with dynamic updates,
frequency division, equivalent time sampling
Internal base clocks 80 MHz, 20 MHz, 100 kHz
External base clock frequency 0 MHz to 20 MHz
Base clock accuracy 50 ppm
Output frequency 0 MHz to 20 MHz
Inputs Gate, Source, HW_Arm, Aux, A, B, Z,
Up_Down
Routing options for inputs Any module PFI, chassis PFI, analog trigger,
many internal signals
FIFO Dedicated 127-sample FIFO
