Brand： National Instruments Model number：PXI-5661
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
hipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
PXI-5661 National Instruments Spare parts in stock
Analog input function Start Trigger, Reference Trigger,
Pause Trigger, Sample Clock, Convert Clock,
Sample Clock Timebase
Analog output function Start Trigger, Pause Trigger, Sample Clock,
Sample Clock Timebase
Counter/timer function Gate, Source, HW_Arm, Aux, A, B, Z,
Up_Down
Digital waveform generation (DO)
function
Sample Clock
Digital waveform acquisition (DI)
function
Sample Clock
Device-to-Device Trigger Bus
PCI RTSI <0..7>4
PXI PXI_TRIG <0..7>, PXI_STAR
USB source None
Output selections 10 MHz Clock, frequency generator output,
many internal signals
Debounce filter settings 125 ns, 6.425 μs, 2.56 ms, disable; high and
low transitions; selectable per input
Bus Interface
PCI/PXI 3.3 V or 5 V signal environment
USB USB 2.0 Hi-Speed or full-speed5, 6
DMA channels (PCI/PXI) 6, can be used for analog input, analog output,
digital input, digital output, counter/timer 0,
counter/timer 1
USB Signal Stream 4, can be used for analog input, analog output,
counter/timer 0, counter/timer 1
The PXI device can be installed in PXI Express hybrid slots. It cannot be used to control SCXI
in PXI/SCXI combo chassis.
4
In other sections of this document, RTSI refers to RTSI <0..7> for the PCI devices or
PXI_TRIG <0..7> for PXI devices.
5
If you are using an USB M Series device in full-speed mode, device performance will be lower and
you will not be able to achieve maximum sample/update rates.
6 Operating on a full-speed bus may result in lower performance.
