ACC4807-350F-16P Kollmorgen Motor Control Module

ACC4807-350F-16P Kollmorgen  Motor Control Module

 General

1.1 About this manual

This manual describes the S748/772 series of digital servo amplifiers (standard version:

48A ...72A rated current). S701 to S724 amplifiers are described in an additional product

manual.

A more detailed description of the expansion cards that are currently available and the

digital connection to automation systems can be found, together with our application

notes, in Acrobat-Reader format on the accompanying CD-ROM (system requirements:

WINDOWS, Internet Browser, Acrobat Reader) in different languages.

Technical data and dimensional drawings of accessories such as cables, brake resistors,

mains supplies, etc., can be found in the accessories manual.

This documentation (PDF) can be printed out on any standard commercial printer. A

printed copy of the documentation is available from us at extra cost.

More background information can be found in our "Kollmorgen Developer Network"

kdn.kollmorgen.com.

1.2 Hints for the online edition (PDF format)

Bookmarks:

Table of contents and index are active bookmarks.

Table of contents and index in the text:

The lines are active cross references. Click on the desired line and the appropriate page

is accessed.

Page/chapter numbers in the text:

Page/chapter numbers with cross references are active. Click at the page/chapter number to reach the indicated target.
