TC809A1067 Honeywell Controller module Brand new

ATTENTION

l (1) Operating Limits define the range of operating conditions within which the

system is designed to operate. Performance characteristics are defined when

operating in this state. Refer to ANSA/ISA D 51.1 for more information.

o Transportation and Storage Limits define the range of conditions to which

the system may be subjected without permanent damage to the

equipment. Performance is not guaranteed in this state. Refer to ANSA/ISA

D 51.1 for more information.

l (2) This rating applies to the internal ambient temperature of the enclosure with the

doors closed.

l (3) The maximum relative humidity spec applies up to 40°C. Above 40°C, the RH spec

is de-rated to 55% to maintain constant moisture content.

l (4) Measured with the field strength meter near the surface of the electronics with

doors open.

l (5) Applied to items those are likely to be in contact with discharge sources (For

example, human body) during typical maintenance actions.

l (6) 10 Hz is approximate – exact crossover frequency is determined by the

intersection of the displacement and acceleration.

l (7) Composite Transportation Test Curve--encompassing maximum Random

Vibration power spectral density values associated with ground, air, and sea

transportation environments.

The rail-mounted UIO is not designed to meet the Marine Application requirement.

8.9 Rail-mounted UIO module assembly

8.9.1 Installation declarations

ATTENTION

This equipment shall be installed in accordance with the requirements of the National

Electrical Code (NEC), ANSI/NFPA 70, or the Canadian Electrical Code (CEC), C22.1. It is

supplied as "open equipment" that is intended to be mounted on a sub-panel within an

enclosure. The suitability of the enclosure and installed system shall be acceptable to the

local "authority having jurisdiction," as defined in the NEC, or "authorized person" as defined

in the CEC.
