Input and output circuits are protected from shorts to alleviate the need for in-line fusing, reducing installation and maintenance costs.
Brand：HONEYWELL Model number：TC-IXR061
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
hipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Servce: Professional Sales provides 24 hours /7 days online service
TC-IXR061 Honeywell Power module Brand new
FOE topologies - Daisy chain topology
A daisy chain topology allows the remote I/O connection to be extended and can be utilized several
times - if maximum flight delay times of data passing between the C300 controller and I/O are not
exceeded.
When Series C daisy chaining,
the electrical port requires no interface cable to be attached. This applies if:
l daisy chaining Series-C link traffic, and
l I/O is not present at the repeating location.
When PM I/O daisy-chaining,
an interface cable must always be connected to the electrical port. This is because the cable keys
the FOE for the PM mode of operation
A repeater function also extends the remote I/O similar to the daisy chain technique, but relies on
the optical ports of two FOE modules to provide the interconnection.
13.4.6 FOE topologies - Star topology
The figures below illustrate the STAR topology whereby remote FOE nodes are individually
connected to a central connection point (e.g. the C300). This topology has the advantage in that if
one cable or cable set fails, the rest of the remote nodes remain operational. For this reason STAR
is the most widely used configuration. The STAR is sometimes referred to as a chicken foot
topology.
.
.
We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
