Series-C I/O modules are constructed to support normal field failures, wiring errors and conditions such as a shorted wire. All Series-C IOTAs contain at least one fuse that provides protection for catastrophic errors in the IOTA, IOM and other elements of the Series-C system. In normal operation as well as many abnormal operations, the fuse element should not blow.
Brand:HONEYWELL
Model number:R4140G-1106
Colour:new
Warranty: 12 months
Lead Time:3-day working day
Country of origin: USA
Price: Please contact us
Product weight:0.22kg
hipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Servce: Professional Sales provides 24 hours /7 days online service
R4140G-1106 Honeywell Input module Brand new
Alarm output and digital input wiring
You can wire #1 and #2 Alarm Outputs and Digital Inputs.
The prerequisites are:
· Model Number - Table 3 = XX1
Refer to Figure 2-19 and follow the procedure in Table 2-18 to wire alarm outputs or digital inputs.
The alarm output is a dry contact closure.
Table 2-18 Alarm output or digital input wiring
Step Action
1 Open the recorder door. Loosen the captive screw in the chart plate and swing the plate out.
2 Locate connector J3 and J4 on the alarm output/digital input printed circuit board (refer to
Figure 2-19 for location).
3 Remove the unwired plug from J3.
4 Run the digital input wires through the desired knockout.
5 For CE Mark conformity, install the ferrite filter as shown in Figure 2-11.
6 Strip insulation from the end of each wire.
7 Loosen the screws in plug J3 terminals and position the plug as you would to plug it into J3.
8 Insert the wires for the digital inputs into the appropriate screw clamps as shown (refer to
Figure 2-19). Note that you can wire the contacts in an and /or fashion, so that both contacts
or either contact initiates the configured action. Tighten the screws to secure the wires.
9 Install the wired plug into J3.
10 Remove the unwired plug from J4.
11 Run the alarm output wires through the desired knockout.
12 For CE Mark conformity:
· install the ferrite filter as shown in Figure 2-11
· install the shield capacitors as shown in Figure 2-19.
13 Strip insulation from the end of each wire.
14 Loosen the screws in plug J4 terminals and position the plug as you would to plug it into J4.
15 Insert the wires for the alarm devices into the appropriate screw clamps as shown (refer to
Figure 2-19). Tighten the screws to secure the wires.
16 Locate the jumper positions W1/W2 and W3/W4 on the printed circuit board. Reposition the
jumpers as shown in Figure 2-19 for the desired relay control action. The recorder is shipped
with the W1 and W3 in N.C. positions.
17 Install the wired plug into J4
.
.
