If multiple instruments need a ground reference the four positions of TB2 can serve as those ground points (assuming the JP17-JP20) jumpers are intact. If more than four grounding screws are needed then a custom wire from TB2 to a separate terminal block can allow for more grounding screw positions.
Brand：HONEYWELL Model number：621-9938
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
hipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Servce: Professional Sales provides 24 hours /7 days online service
621-9938 Honeywell Central control module Brand new
ATTENTION
The safety ground on the FOE module must be wired to the chassis ground of the system
cabinet.
13.5.9 Connecting the power cables to the single mode FOE on DIN
rail
The FOE modules mounted on the DIN rail can derive power from one of the following power
supply options.
l Meanwell/Phoenix Contact
l TDI
The following table provides information on the power supply options and the appropriate
Honeywell part number.
Power supply option Honeywell part number
(power cable)
Meanwell/Phoenix Contact 51202930-200
TDI 51202948-100
(Two FOE modules)
TDI 51202948-200
(One FOE module)
13.5.10 Using Meanwell/Phoenix Contact power supply
The following figure illustrates the power connections to the FOE module from Meanwell/Phoenix
Contact.
- 524 -
Chapter 13 - Series C I/O Link Fiber Optic Extenders (FOE)
Chapter 13 - Series C I/O Link Fiber Optic Extenders (FOE)
Refer to the following instructions for making power connections from Meanwell/Phoenix Contact
to the FOE module on DIN rail.
1. Connect the power cable 51202930-200 (two red and one black cable) to the terminal block on
DIN rail. Perform the following steps to do so:
l Open the fuse holder using the lever provided.
l Insert the ferrule of the cable into the fuse terminal on the side.
l Fasten the screw inside the terminal block, below the fuse holder.
2. Connect one end of the 5-inch red cable into the fuse terminal marked '-' on the terminal block
and the other end to the 'V+' terminal of the power connector on the FOE module. You can do
so by inserting the ferrule inside the terminal and fastening the corresponding screw inside
the terminal block.
3. Connect the 80-inch red cable from the '+' terminal of the feed through terminal block in the
system cabinet to the fuse terminal marked '+' on the terminal block on DIN rail.
4. Connect the 80-inch black cable from the '-' terminal of the feed through terminal block in the
system cabinet to the 'V-' terminal of the power connector on the FOE module.
.
.
We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
