Because the maximum transmitter output level is -7 dB, and the maximum receiver input level is -10 dB, the receiver may be overdriven on a short link and may require a 3 dB attenuator. Connector allowances for the transmitter and receiver are included in the above power declaration.
Brand：HONEYWELL Model number：620-0076
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
hipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Servce: Professional Sales provides 24 hours /7 days online service
620-0076 Honeywell Power module Brand new
l Single mode FOE configuration
l Pull High/Low resistor setting
l DIP switch settings
13.5.1 Key features of single mode FOE
l Single mode fiber that can extend the IOLINK up to 10 km.
l Three-way communication: RS-232, fiber and RS-422/485.
l Rotary switch to change the pull high/low resistor value
l Extend RS-232/422/485 transmissions up to 440 km with single-mode. However, FOE module
on IOTA supports up to 10 km only.
l Reverse power protection.
l Support baud rate up to 921.6 Kbps.
l Class I, Div. II certification.
The single mode fiber optic converter extends RS232/422/485 transmission up to 10km long with
single mode fiber.
The following figure displays a sample IO link arrangement.
13.5.2 Key features of single mode converter
l Fiber optic support for Honeywell IO Link optional speed selection for 750/375 kbits/s.
l Provides fiber to copper conversion and re-transmitted fiber signals.
l The optical power emitted is less than 0.5mW.
l CE marked.
Features Description
Supported family Series C, Process Manager
Topology types
l Point-to-point
.
.
We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
