Millivolt signals are not counted by the PIM unless a suitable preamplifier is used to boost the signal to a level that can be detected by the PIM circuitry. l Current Pedestal signaling is not directly supported by PIM circuitry.
Brand：HONEYWELL Model number：620-0033
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
hipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Servce: Professional Sales provides 24 hours /7 days online service
620-0033 Honeywell Controller module Brand new
The Fiber Option Extender modules support the extension of the I/O link beyond the Series C
Cabinet with the C300, enabling remote applications of the Series C I/O.
The following two types of FOEs are qualified to be used with Experion depending on the distance
between the controller and the IO modules.
l Multi-mode FOE
l Single mode FOE
You can select the appropriate FOE based on your requirement.
l Overview of multi-mode FOE
l FOE Installation
l Component mounting sequence
l Defining the Fiber Optic topology
l Single mode fiber optic extender
l Defining the single mode fiber optic topology
13.1 Overview of multi-mode FOE
The Fiber Optic module and IOTA board are built exclusively for Honeywell by a third party
company. With a Series C I/O Link Fiber Optic Extender (FOE) module, the ability exists to connect
the C300 controller to remote:
l Series C I/O and
l PM I/O
The FOE has the following capabilities:
l To connect one local cabinet to two remote I/O sites.
o If more than two remote sites exist, multiple FOE modules may be installed in the
local cabinet.
l Has two fiber optic ports sets, FO1 and FO2,
o each set having both a receive (Rx) and transmit (Tx) connector.
l An IOLINK connector for connecting to the copper IOL.
NOTE
The same FOE module cannot be used for both types Series C and PM I/O concurrently.
The following FOE connections can be made:
.
.
We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
