Millivolt signals are not counted by the PIM unless a suitable preamplifier is used to boost the signal to a level that can be detected by the PIM circuitry. l Current Pedestal signaling is not directly supported by PIM circuitry.
Brand：HONEYWELL Model number：620-0027
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
hipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Servce: Professional Sales provides 24 hours /7 days online service
620-0027 Honeywell Controller module Brand new
The controller enclosure is constructed of a plastic base
plate and a plastic factory-snap-on cover. The cover does
not need to be removed from the base plate for either
mounting or wiring. Removable terminal blocks are used
for all wiring connections, which allow the controller to be
wired before or after mounting.
The controller can be mounted in any orientation.
Ventilation openings are designed into the cover to allow
proper heat dissipation, regardless of the mounting
orientation.
NOTE: The controller must be mounted in a position that
allows clearance for wiring, servicing, and
removal.
NOTE: For complete mounting information, refer to the
Installation Instructions, form 62-0310.
PVBXXXXAS Mounting (Controllers with
actuators)
The PVBXXXXAS controllers include the direct-coupled
actuator with Declutch mechanism, which is shipped
hard-wired to the controller (using digital outputs 7 and
8).
The actuator mounts directly onto the VAV box damper
shaft and has up to 44 lb-in. (5 Nm) torque, 90-degree
stroke, and 90 second timing at 60 Hz. The actuator is
suitable for mounting onto a 3/8 to 1/2 in. (10 to 13 mm)
square or round VAV box damper shaft. The minimum VAV
box damper shaft length is 1-9/16 in. (40 mm).
After the actuator is mounted to the damper shaft, the
controller mounts to a panel by using four No. 6 or No. 8
machine or sheet metal screws inserted through the
corners of the base plate.
.
.
We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
HONEYWELL 30750338-005
HONEYWELL 51403393-100
HONEYWELL 30751044-4
HONEYWELL 30751044-009
HONEYWELL 30751044-7
HONEYWELL 51403393-200
HONEYWELL 4DP7APXIO211
HONEYWELL 30750318-2
HONEYWELL 30750318-3
HONEYWELL 51196882-100
HONEYWELL 51304095-100
HONEYWELL 51400997-200
HONEYWELL 51401088-100
HONEYWELL 51400926-100
HONEYWELL 51304537-100
HONEYWELL 51401583-200
HONEYWELL 51401583-100
HONEYWELL 51401996-100
HONEYWELL 51304421-100
HONEYWELL 51304441-175
HONEYWELL 51107137-117
HONEYWELL 51196654-100
HONEYWELL 51196653-100
HONEYWELL 51400712-100
HONEYWELL 51204166-175
HONEYWELL 51401201-100
HONEYWELL 51401577
