If multiple instruments need a ground reference the four positions of TB2 can serve as those ground points (assuming the JP17-JP20) jumpers are intact. If more than four grounding screws are needed then a custom wire from TB2 to a separate terminal block can allow for more grounding screw positions.
Brand：HONEYWELL Model number：51403282-200
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
hipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Servce: Professional Sales provides 24 hours /7 days online service
51403282-200 Honeywell Controller module Brand new
Select the input stream type in the Input Stream Type box. You can select one of the following:
l Single Stream - You can select this option for all channels.
l Dual Stream - You can select this option only for odd-numbered channels.
Whenyou configure a channel for Dual Stream, its associated even-numbered channel
number appears in the Associated Channel Number box.
For example, if you have configured channel 1 for dual stream, the channel number 2 appears
in the Associated Channel number box.
ATTENTION
l When you select the pulse input channel type as Pulse Input with Fast Cutoff
for Fast Cutoff channels (channel 7 and channel 8), Single Stream is selected
by default and is non-editable.
l When you select the pulse input channel type as Pulse Input, you can
configure Dual Stream on the Fast Cutoff channels (channel 7 and channel 8).
l Dual Stream option is not applicable for Fast Cutoff channels (channel 7 and
channel 8) when the Pulse Input Channel type as Pulse Input with Fast Cutoff.
In this scenario, the option Single Stream is selected by default and is noneditable.
l If you select the Input Stream Type as Dual Stream for odd-numbered
channels, then you cannot configure their associated even numbered
channels. For example, if you have configured channel 1 as Dual Stream, you
cannot configure channel 2. In addition, the associated channel does not
appear in the tree view if you have configured the channel for Dual Stream.
l If the CM already contains the even-numbered channel and you try to
configure its associated odd-numbered channel as Dual Stream, an error
message appears. You need to delete the associated even-numbered channel
from the CM. For example, if a CM contains channel 3 and channel 4, and you
try to configure channel 3 as Dual Stream, an error message appears. You
need to delete channel 4 to configure channel 3 as Dual Stream.
l When a channel is configured for Dual Stream, the Status Data tab of the PIM
does not display any values for the associated channel in the Monitoring view.
For example, if you have configured channel 3 for Dual Stream, the channel 4
row in the Status Data tab does not display any values.
.
.
We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
