To configure the DO channel for ganging

1. Click File > New >I/O Modules > Series_C_I_O > UIO – Universal I/O, 32 channels.

The UIO module appears in the Project view under the Unassigned items.

2. Assign the UIO module to an IOLINK that is configured as "SERIES_C_IO_TYPE."

3. From the Project view, right-click the UIO channel and then click Block Properties.

The UIO channel configuration form appears.

4. Click the Channel Configuration tab.

The Channel Configuration tab configuration form appears. The point type is selected as DI,

by default.

5. Configure the Channel Point Type as DO for which ganging needs to be enabled.

ATTENTION

An error message appears if you try to change the channel type when the channel

is configured in any Control Module.

6. Click OK.

7. Click File > New > Control Module.

The Control Module chart opens.

8. Drag the DO channel from the Project view to the Control Module chart.

9. Double-click the DO channel.

The DO channel configuration form appears.

10. Click the Configuration tab.

The Configuration tab configuration form appears.

11. Select the Enable Ganged Outputs check box.

The Number of Channels Ganged drop-down list is enabled for configuration.

12. Select the number of channels to be ganged from the Number of Channels Ganged dropdown list.

You may encounter errors if one of the following scenarios exists.

l Adjacent channel is not configured as DO channel.

l DO channel, which needs to be configured for ganging, is already configured in any

Control Module.

13. Click OK.

14. Save and close the Control Module chart.

15. Assign and load the Control Module.
