Brand：HONEYWELL Model number：51303994-300
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
hipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Servce: Professional Sales provides 24 hours /7 days online service
51303994-300 Honeywell Controller module Brand new
Function
The Analog Input Module accepts high level current or voltage inputs from transmitters and sensing devices.
Notable Features
• Extensive self-diagnostics
• Optional redundancy
• Supplies non-incendive field power
• Non-Incendive Power
• Fast loop scan
Detail Specifications –Analog Input
Parameter Specification
Input / Output Model CC-PAIX02 - High-Level Analog Input
IOTA Models Non-Redundant Redundant
CC-TAIX01 CC-TAIX11
CC-GAIX21 CC-GAIX11
CC-TAID01 CC-TAID11
Input Type 1 Voltage, current (2-wire or self-powered transmitters)
Input Channels 1 16 Channels (12 Single Ended / 4 Differential )
Common Mode Rejection Ratio, dc to 60 Hz (500 W
source imbalance)
70 dB
Common Mode Voltage, dc to 60 Hz -6 to +5 V peak
A/D Converter Resolution 16 bits
Input Range 1 0 to 5 V, 1 to 5 V, 0.4 to 2 V, 4-20 mA (through 250 Ω)
Normal Mode Rejection Ratio, at 60 Hz 19 dB
Normal Mode Filter Response Single-pole RC, -3 dB @ 6.5 Hz
Maximum Normal Mode Input (differential inputs, no
damage)
± 30 Volts
Crosstalk, dc to 60 Hz (channel-to-channel) -60 dB
Input Impedance (voltage inputs) > 10 M Ω powered
Input Scan Rate 50 ms
Hardware Accuracy (@ CMV = 0 V) ± 0.075% of full-scale (23.5°± 2°C)
± 0.15% of full-scale (0 to 60°C)
Transmitter Field Power Conditioning Individually Protected Current Limiting Circuits for Class 1,
Div 2 non-incendive interfacing. No fusing required
.
.
