51303991-300   Honeywell   Controller module Brand new

51303991-300 Honeywell Controller module Brand new

In virtually all configurations, the C300 controller and Series C I/O provides useful, maintainable process equipment  connections in a smaller footprint than existing competitors and Honeywell equivalent products. Installing Series C I/O modules contributes to overall total installed cost savings.

Brand:HONEYWELL   Model number51303991-300

Colour:new                  Warranty: 12 months

Lead Time:3-day working day   Country of origin: USA

Price: Please contact us         Product weight:0.22kg

hipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Servce: Professional Sales provides 24 hours /7 days online service

51303991-300   Honeywell   Controller module Brand new



51303979-500   Honeywell   Controller module Brand new

Function

The Analog Input Module accepts high level current or voltage inputs from transmitters and sensing devices.

Notable Features

• Extensive self-diagnostics

• Optional redundancy

• Supplies non-incendive field power

• Non-Incendive Power

• Fast loop scan

Detail Specifications –Analog Input

Parameter Specification

Input / Output Model CC-PAIX02 - High-Level Analog Input

IOTA Models Non-Redundant Redundant

CC-TAIX01 CC-TAIX11

CC-GAIX21 CC-GAIX11

CC-TAID01 CC-TAID11

Input Type 1 Voltage, current (2-wire or self-powered transmitters)

Input Channels 1 16 Channels (12 Single Ended / 4 Differential )

Common Mode Rejection Ratio, dc to 60 Hz (500 W

source imbalance)

70 dB

Common Mode Voltage, dc to 60 Hz -6 to +5 V peak

A/D Converter Resolution 16 bits

Input Range 1 0 to 5 V, 1 to 5 V, 0.4 to 2 V, 4-20 mA (through 250 Ω)

Normal Mode Rejection Ratio, at 60 Hz 19 dB

Normal Mode Filter Response Single-pole RC, -3 dB @ 6.5 Hz

Maximum Normal Mode Input (differential inputs, no

damage)

± 30 Volts

Crosstalk, dc to 60 Hz (channel-to-channel) -60 dB

Input Impedance (voltage inputs) > 10 M Ω powered

Input Scan Rate 50 ms

Hardware Accuracy (@ CMV = 0 V) ± 0.075% of full-scale (23.5°± 2°C)

± 0.15% of full-scale (0 to 60°C)

Transmitter Field Power Conditioning Individually Protected Current Limiting Circuits for Class 1,

Div 2 non-incendive interfacing. No fusing required



.


.


We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation!

HONEYWELL    30750338-005

HONEYWELL    51403393-100

HONEYWELL    30751044-4

HONEYWELL    30751044-009

HONEYWELL    30751044-7

HONEYWELL    51403393-200

HONEYWELL    4DP7APXIO211

HONEYWELL    30750318-2

HONEYWELL    30750318-3

HONEYWELL    51196882-100

HONEYWELL    51304095-100

HONEYWELL    51400997-200

HONEYWELL    51401088-100

HONEYWELL    51400926-100

HONEYWELL    51304537-100

HONEYWELL    51401583-200

HONEYWELL    51401583-100

HONEYWELL    51401996-100

HONEYWELL    51304421-100

HONEYWELL    51304441-175

HONEYWELL    51107137-117

HONEYWELL    51196654-100

HONEYWELL    51196653-100

HONEYWELL    51400712-100

HONEYWELL    51204166-175

HONEYWELL    51401201-100

HONEYWELL    51401577
