51198685-100 Honeywell

Specifications for Series-C I/O modules are shown below.

For information on environmental specifications, please refer to the Series-C Platform Specification and Technical data

sheet EP03-520-xxx.

5.1. Analog Input with HART – CC-PAIH01 / 02

Function

The Analog Input Module accepts high level current or voltage inputs from transmitters and sensing devices.

Notable Features

• Extensive self-diagnostics

• Optional redundancy

• Open Wire Detection

• Supplies non-incendive field power

• Non-incendive Power

• HART-capable, multivariable instruments and multiple

modems for fast collection of control variables

• Fast loop scan

• PV protection through an open wire detection

diagnostic

• Open-wire Bad PV Detection

Detail Specifications – Analog Input with HART

Parameter Specification

Input / Output Model CC-PAIH02 - High-Level Analog Input with HART

IOTA Models Non-Redundant Redundant

CC-TAIX01 CC-TAIX11

CC-GAIX21 CC-GAIX11

CC-TAID01 CC-TAID11

Input Type Voltage, current (2-wire or self-powered transmitters)

Input Channels 1 16 Channels (12 Single Ended / 4 Differential )

Common Mode Rejection Ratio, dc to 60 Hz (500 W

source imbalance)

70 dB

Common Mode Voltage, dc to 60 Hz -6 to +5 V peak

A/D Converter Resolution 16 bits

Input Range 1 0 to 5 V, 1 to 5 V, 0.4 to 2 V, 4-20 mA (through 250 Ω)

Normal Mode Rejection Ratio, at 60 Hz 19 dB

Experion Series-C I/O Specification, EP03-490-520 9

Version 1.5 Honeywell Proprietary Dec 2021

Parameter Specification

Normal Mode Filter Response Single-pole RC, -3 dB @ 6.5 Hz

Maximum Normal Mode Input (differential inputs, no

damage)

± 30 Volts

Crosstalk, dc to 60 Hz (channel-to-channel) -60 dB

Input Impedance (voltage inputs) > 10 M Ω powered

Input Scan Rate 50 ms

Hardware Accuracy (@ CMV = 0 V) ± 0.075% of full-scale (23.5°± 2°C)

± 0.15% of full-scale (0 to 60°C)

Transmitter Field Power Conditioning Individually Protected Current Limiting Circuits for Class 1,

Div 2 non-incendive interfacing. No fusing required

Note 1: CC-PAIH01 supports voltage inputs for channels 13-16 CC-PAIH02 supports voltage inputs for channels 1-16 when used

with CC-TAIDx1 IOTA. Each channel's 250-Ohm load resistor is connected to the input terminal through a wire jumper on

the IOTA. This jumper should be cut by the user on channels to be used with voltage transmitters. For channels 13-16 the

low-side input connection is normally connected to system common by a wire jumper on the IOTA. This jumper may be cut

by the user to enable differential operation subject to operating within the CMV specification.
