The controller can be mounted in any orientation.
Ventilation openings are designed into the cover to allow
proper heat dissipation, regardless of the mounting
orientation.
Brand：HONEYWELL Model number：30750783-003
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
hipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Servce: Professional Sales provides 24 hours /7 days online service
30750783-003 Honeywell Controller module Brand new
SPECIFICATIONS
Electrical
Rated Voltage: 20-30 Vac; 50/60 Hz
Power Consumption:
100 VA for controller and all connected loads (including
the actuator on model PVB6436AS)
Controller only Load: 5 VA maximum; models PVB6438NS,
PUB6438S, and PUB6438SR
Controller and Actuator Load: 9 VA maximum; model
PVB6436AS
External Sensors Power Output: 20 Vdc ±10% @ 75 mA
maximum
Environmental
VAV Operating & Storage Temperature Ambient Rating
(models PVB0000AS, PVB4022AS, PVB4024NS,
PVB6436AS, and PVB6438NS):
Minimum 32° F (0° C); Maximum 122° F (50° C)
Unitary Operating & Storage Temperature Ambient Rating
(models PUB1012S, PUB4024S, PUB6438S, and
PUB6438SR):
Minimum -40° F (-40° C); Maximum 150° F (65.5° C)
Relative Humidity: 5% to 95% non-condensing
Dimensions (H/W/D)
See Fig. 1 to Fig. 4 beginning on page 6 for dimensioned
drawings.
PUB1012S, PUB4024S, and PVB4024NS:6.25 x 4.81 x
2.26 in. (15.92 x 12.20 x 5.74 cm)
PVB0000AS, PVB4022AS (including Actuator):
6.60 x 8.28 x 2.26 in. (16.70 x 21.10 x 5.74 cm)
PVB6436AS (including Actuator): 6.27 x 10.316 x 2.26 in.
(15.92 x 26.20 x 5.74 cm)
PVB6438NS: 5.76 x 6.85 x 2.26 in. (14.62 x 17.40 x 5.74 cm)
PUB6438S, PUB6438SR: 5.45 x 6.85 x 2.26 in. (13.84 x
17.40 x 5.74 cm)
.
.
