30750318-3 Honeywell Input module Brand new

Control Level SCANCTRLLVL Yes Indicates Server control level to be

associated with this function.

Number of History

Parameters

HIST.NUMPARAMS Yes Defines number of history parameters to be

included in History Configuration table.

Parameter HIST.PARAM Yes Valid parameter name for a parameter

associated with the given point that is to be

collected and stored as historical data at

predetermined intervals.

Description No Provides a brief description of the entered

parameter.

FAST HIST.FAST Yes Select the Fast type of history collection.

STD HIST.STD Yes Select the Standard type of history

collection.

EXTD HIST.EXTD Yes Select the Extended type of history

collection.

EXC HIST.EXC Yes

(Station

only)

Select the Exception type of history

collection.

Gating Parameter Yes Optional gating parameter to define

conditions under which data for this

parameter should be collected.

Gate State Yes Defines gate state for configured gating

Table 9.4 Server History tab parameters

- 322 -

Chapter 9 - Series C I/O Configuration Form Reference

Chapter 9 - Series C I/O Configuration Form Reference

Plain text Parameter name User

configurable

Notes

parameter.

Create New or Edit

Existing Server

Scripts (Button)

N/A Launch the Server scripting configuration

utility.

9.6.1 Prerequisites

l Control Builder is running

l A Series C I/O control module was created

9.6.2 To configure the Server History tab.

1. Under the Server History tab, enter the appropriate information for Control Level along with

values for appropriate parameters related to history collection and archiving. If necessary,

press F1 to access on-line help for assistance during this step.

2. Proceed to the following procedures to configure parameters on the remaining tabs for I/O

Module, or click OK to accept only the changes made so far and return to the Project tree.
