In no event is Honeywell liable to anyone for any direct, special, or consequential damages. The information and specifications in this document are subject to change without notice.
Brand：HONEYWELL Model number：10205-2-1
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
hipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Servce: Professional Sales provides 24 hours /7 days online service
10205-2-1 Honeywell Programmable controller Brand new
From Control Builder, you can select Low or High voltage thresholds depending upon the sensors
used. Generally, if the sensor outputs a signal in the 0V to 5V range (for example, TTL), the Low
threshold is the best choice. If the sensor’s pulse output is an open collector or open drain type
and the externally supplied Pull-up resistor is used on the IOTA, the High threshold is the best
choice as the signal swings from 0V to about 23V. Other devices that are actively driven require
knowledge of the output swing to determine the proper range. For example, the Swinton
Technology ST500 Dual-Pulse Simulator outputs have a voltage swing of 0V to 12V with respect to
the 0V terminal. Therefore, either the Low or the High threshold can be selected, but there will be
slight difference in the measured Pulse Length (PL) parameter.
ATTENTION
l Millivolt signals are not counted by the PIM unless a suitable preamplifier is used to
boost the signal to a level that can be detected by the PIM circuitry.
l Current Pedestal signaling is not directly supported by PIM circuitry.
The following table lists the typical thresholds for the Low and High ranges.
Input Threshold Setting Trip point for Rising Input
(Low to High transition)
Trip Point for Falling Input
(High to Low transition)
Hysteresis
(typical)
Low 2.75 V 2.04 V 0.71 V
High 8.41 V 7.7 V 0.71 V
.
.
We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
