7VRCK001CD03 GE Input module Brand new

Brand： GE                 Model number：7VRCK001CD03

Colour：new                  Warranty:  1 year

Lead Time：3-day working day   Country of origin: USA

Price: Please contact us         Product weight：0.12kg

hipping Port: China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

7VRCK001CD03  GE   Input module Brand new

If current mode (4-20mA) is used for an input without an external

resistor, connect a jumper from the terminal marked JMP to the terminal

marked RTN for that circuit.

If an input current device operates outside the 4-20mA range, connect a

resistor across the voltage inputs. For example, to measure 10mA to

50mA current loop signals, install a 100 ohm resistor.

If current mode is used for an output circuit, use the terminals marked I+

and I-. For outputs set up in current mode, the block’s internal power

supply can be used to drive loads up to 300 Ohms per output. For loads

up to 2K Ohms, use an external power supply. Connect the positive

lead of the external supply to one side of the load, and the negative lead

of the external supply to block common on terminal 29. If the external

supply is between 24V and 50V, you can use terminal 25 or 30 as a tie

point for the positive connection. This point will be disconnected from the

external supply by a reverse biased diode.

Removing an Electronics Assembly _______________

The block’s Electronics Assembly can be replaced with a compatible

model without removing field wiring or reconfiguring the block.

Terminal

Assembly

Retaining

Screws

(Qty. 2)

Electronics

Assembly

Connector

Pins

1. Unscrew the retaining screws at the top and bottom of the block.

2. Using a Block Puller (IC660BLM507), engage the tabs in the first

vent slots. Move the tool to the center of the block and squeeze the

handle.

3. Pull the Electronics Assembly upward
