75C142464-ET-G926-S6N-60  GE  Controller module Brand new

75C142464-ET-G926-S6N-60 GE Controller module Brand new

After extended usage of SVC_REQ 57, a problem could occur upon power-cycle. The symptom was an error in the fault table, with Group 140 Error code 3, and the following bytes in the fault extra data (starting at the

fifth byte): 80 1E 00 A5. This problem prevented SVC_REQ 56/57 from being used, and the only way to resolve the problem was to clear the flash memory.


Brand: GE                 Model number:75C142464-ET-G926-S6N-60

Colour:new                  Warranty:  1 year

Lead Time:3-day working day   Country of origin: USA

Price: Please contact us         Product weight:0.12kg

hipping Port: China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

75C142464-ET-G926-S6N-60  GE  Controller module Brand new


Terminals 5 to 32 are for field devices. They take a single wire up to

AWG #14 (avg 2.1mm2

 in cross-section). Minimum recommended

size is AWG #20 (avg .54mm2

 in cross-section).

Wiring for Block Power

For block power, connect the power source to terminals 6 and 7.

For a 24/48 VDC block, connect the source to the DC+ terminal and

the return to the DC- terminal. For a 115 VAC block, connect the

source to the H terminal and neutral to the N terminal.

For the 115 VAC block version (IC66*BBA100) only, if Class 1

Division 2 conditions must be met for Factory Mutual, install an

external 250 volt 1/8 amp slow-blow fuse in series with the Hot AC

power connector as shown below.



H

N

250V, 1/8 Amp Slow-Blow Fuse

6

7

~

Wiring for I/O Devices

The ground (GND) terminal (5) is for block safety. It is connected

internally to the block chassis, and to terminals 12, 20, and 28,

which are marked GND. Each pair of signals has one ground

terminal and one common terminal, for shield termination if desired.

The three common terminals are connected together internally to the

source.
