531X191RTBALG3 RTB TB OPTION CARD GE Power module Brand new

does not work for multi-level directory

path

The "rmdir" Station Manager command does not operate properly with a

multi-level directory path. Instead, first change to the parent directory,

then delete the target directory without specifying a path. For example, the

"rmdir dir1/dir2" results in "RMDIR Failed, dir1/dir2 does not exist".

Instead, first do "cd dir1" and then "rmdir dir2".

Intermittent Ethernet log event 8H/15H

after power cycle

When starting after a power cycle, the Ethernet Interface may

intermittently log an exception (entry 8H, Entry 2 = 15H, Entry 3 = 0000H,

Entry 4 = 00aaH). This exception is benign and may be ignored.

Intermittent Modbus/TCP Server log

events when using "killms" Station

Manager command

When using the "killms" Station Manager command to manually terminate

an active Modbus/TCP server connection, the following Modbus/TCP

errors may occur in the Ethernet exception log: Event 2fH, Entry 2 =

209H, 212H, 21bH, or 221H. These errors may be ignored.

A890 CommReq status after multiple

ModBus Open Command attempts

When using a CommReq to open a Modbus/TCP Channel to a remote

server, if the initial CommReq returned an AA90 status, future Open

Commands may return an A890 status. This indicates that local

networking resources have been consumed and are not available for

further connection attempts. If this occurs, the application must wait at

least 60 seconds before making the next connection attempt. This will

allow networking resources to be released and made available for the

next Modbus Open Command.

Modbus/TCP request packets The Modbus/TCP server expects to receive each Modbus/TCP request in

a separate TCP packet. If multiple requests are sent in a single packet,

the server may or may not send a response to each request. If responses

are sent to the client, they will be sent in separate TCP packets.

EGD production delayed after RMS of

EGD

When a produced EGD exchange is added or modified by a Run-mode

Store, the exchange will not be produced until one production period of

time has elapsed after the completion of the run-mode store.

Station Manager PING commands When initiating ICMP echo requests from the PLC via Station Manager’s

PING command, the operation occasionally fails and an exception is

logged (Event eH, Entry 2 = 6H).

Station Manager “referr” tally The EGD Station Manager “referr” tally may be incremented twice when

an exchange timeout occurs. Exchange status word reporting works

correctly and is not impacted.

“wkal_idle” AUP parameter should not

allow zero

Zero is allowed for the “wkal_idle” (TCP keep alive timer) but it is an

invalid value.

TCP connection may time out early if

the timeout is set above 10 minutes

If the TCP connection timeout is set higher than 10 minutes, the

connection may timeout before the configured value. The connection

timeout is derived from three AUP parameters:

wkal_idle + (wkal_cnt + 1) * wkal_intv
