531X112P5AARG2 GE Power module Brand new

Client Channels TCP resource

management

The OS Network stack hangs on to the TCP resources associated with a

connection for a period of time after the connection is closed. This time

period applies to the initiator of the close, which is almost always the client

side. This time is referred to as the “TCP Linger Period”. Once the TCP

Linger Period expires (60 seconds in the current OS implementation), the

TCP resources are released. Application developers using client channels

need to be aware of this behavior when designing their logic. A finite

number of TCP resources are allocated to client channels, and if channel

connections are brought up and down so fast that these resources are

depleted, then the application may have to wait until a TCP resource frees

up in order to establish another client channel (a COMMREQ Status of

0xA890 is returned if no TCP resources are currently available;

application should wait and try again).

SRTP Client Channels provides features that help the user preserve TCP

connections. These include a period time where one can establish an

SRTP Channel and specify the channel to run at a given interval, or run

as fast a possible. One can also specify a number of iterations, or allow

the channel to run forever. Additionally, SRTP Channels allows channel

re-tasking of an active channel to the same remote device, where the

parameters of an active channel, such as changing the channel command

type (Read/Write), number of repetitions, time periods, local memory

address, remote memory address, etc. can be changed. SRTP Channels

also allows channel re-tasking of an active channel to a different remote

device (changing the remote device’s IP address, etc.). However, retasking to a different remote device will neither conserve TCP

connections, nor save on the time it takes to create a channel.

Client Channels and Redundant IP In a Redundancy System, Client Channel COMMREQs can only be

initiated from the unit that owns the Redundant IP address. Therefore, the

user application logic should use Bit 6 in the LAN Interface Status bit area,

“Redundant IP Active” as part of their enabling logic that drives a client

channel COMMREQ.

An attempt to open 17 or more Modbus

server connections may appear

successful

If more than the maximum 16 supported Modbus Server Connections are

attempted, the TCP connection may succeed, but no data may be

subsequently transferred.
