44C331828-G01 GE Controller module Brand new

Brand： GE                 Model number：44C331828-G01

Colour：new                  Warranty:44B712895-002

Lead Time：3-day working day   Country of origin: USA

Price: Please contact us         Product weight：0.12kg

hipping Port: China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

44C331828-G01  GE  Controller module Brand new

DLAN/DLAN+ (Drives Local Area

Network) Interface restrictions

PACSystems RX7i CPUs with firmware versions 1.50 or later support

DLAN Interface, IC697BEM763 modules with firmware versions 3.00

or later. You must ensure that you are using a valid version of the

DLAN firmware because the CPU cannot check the DLAN’s firmware

version. (The module’s firmware version can be found on a label

attached to the EEPROM.)

If your RX7i application program needs to access the DLAN’s dual port

memory, use the BUS READ and WRITE functions. When accessing a

DLAN module, set the Region parameter on the function block to 1.

(For the DLAN module, region 1 is predefined to be the module's

entire dual port memory.)

The DLAN is only supported in the main RX7i rack. It is not supported

in expansion racks.

Note: The DLAN Interface module is a specialty module with limited

availability. If you have a DLAN system, refer to the

DLAN/DLAN+ Interface Module User’s Manual, GFK-0729 for

details.

Genius Bus Controller restrictions The following restrictions apply to GBCs in PACSystems RX7i:

▪ The minimum CPU sweep time will be gated by the time it takes

the GBC to refresh its outputs and collect its inputs + 500

microseconds. To obtain a smaller sweep time, use the SUSIO

function block or place the GBCs in a scan set that has nondefault characteristics.

▪ If a %W reference address is used for COMMREQ status or

return data, it must be in the range %W00001 - %W65536.

▪ Storing or clearing a hardware configuration containing two GBCs

attached to the same Genius network may cause a Loss of

Device fault for one of the GBCs. This is caused by the GBCs

clearing their SBAs asynchronously. The user can safely ignore

the Loss of Device fault.

PCM (to CPU) communications

timeout

The PCM has a default backplane communications timeout value of 5

seconds. After the PCM has sent a request to the CPU, the PCM

applies this timeout while waiting on a response back from the CPU. In

most cases, the CPU will respond well within the 5–second timeout;

however, in certain instances the CPU can take longer than 5 seconds

to respond. These cases are limited to LOADs or STOREs of program

and/or configuration -especially if blocks in the program are larger than

8 KBytes. Folders containing EXE blocks (again with *.EXE files >8

KBytes) are most likely to cause problems. To ensure that the PCMs

do not observe backplane timeouts, a file must be loaded (using termf)

to the PCM. The file must be a binary file named CPU.ENV. The

contents of this file are as below (all values are specified in

hexadecimal):

Once the binary file CPU.ENV (below) is created, use termf to load

CPU.ENV to the PCM. Then execute a soft reset of the PCM. After

executing the soft reset, the PCM’s backplane communications

timeout should be 10 seconds.

Note: A copy of the above CPU.ENV file can be obtained from

http://www.ge-ip.com/support.
