44A297034-G03 GE Central control module Brand new

No CPU fault logged when Ethernet

Interface in fatal blink code

The CPU does not log any Controller or I/O Faults when the Ethernet

Interface has a fatal blink code. The user’s application should monitor the

LAN interface OK status bit to detect loss of module.

EGD I/O has unexpected variability

under heavy load

EGD I/O has intermittent unexpected variability under heavy load. For a

Produced Exchange, EGD samples may occasionally be delayed by as

much as a production period or more.

Clear of large hardware configurations

may cause log event 08/20

A Log event 08/20 may occur when very large hardware configurations

are cleared and transfers are active on other Server connections. This log

event can be safely ignored.

COMMREQ Status Word of 0x54A0

occasionally returned for EGD

commands

Occasional COMMREQ Status Word values of 0x54A0 are returned to

COMMREQs for EGD commands when the previously transferred

command has experienced retries in the network. Executing the

COMMREQ again results in successful transfer of the command.

Modbus/TCP channel aborted during

power cycle

After powering up an RX7i running Modbus/TCP client channels, the

establish connection occasionally fails because the server occasionally

rejects the "open" from the client. The connection will then succeed if the

application retries the open when it sees a 0x9690, 0xAA90, or B490H

response to an open request or to the first write request.

RX7i response timeout errors (8/08) in

Ethernet exception log under extremely

heavy SRTP traffic

Under extremely heavy SRTP traffic conditions, the Ethernet Interface

may log an event in the Ethernet exception log (Event 8, Entry 2 = 08H)

indicating an overload condition. This error terminates the SRTP

connection. If this event appears, either the traffic load should be

reduced, or the application should use an alternate communications

method to verify that critical data transfers were not lost due to the

overload.

SRTP channel transfers may take up to

20 seconds after power cycle

When SRTP communications are interrupted by a power cycle, the

Ethernet interface may require up to 20 seconds to reestablish TCP

connection used for SRTP communications
