Large number of COMMREQs sent to

module in one sweep causes faults

A large number of COMMREQs (typically greater than 8) sent to a

given board in the same sweep may cause Module Software faults to

be logged in the Controller fault table. The fault group is

MOD_OTHR_SOFTWR (16t, 10h) and the error code is

COMMREQ_MB_FULL_START (2). When this occurs, the “FT” output

of the function block will also be set. To prevent this situation,

COMMREQs issued to a given board should be spread across

multiple sweeps so that only a limited number (typically 8 or less) of

COMMREQs are sent to a given board in each sweep. In addition, the

FT output parameter should be checked for errors. If the FT output is

set (meaning an error has been detected), the COMMREQ could be

re-issued by the application logic.

C Block standard math functions do not

set errno

In C Blocks, standard math functions (e.g. sqrt, pow, asin, acos) do

not set errno to the correct value and do not return the correct value if

an invalid input is provided.

Loss of VDD100, VAL132 or VME-1182A

after multiple power cycles

In rare instances, a VDD100, VAL132, or VME-1182A module may not

configure after power has cycled repeatedly in a very brief period of

time. A Loss of IO Module fault will be generated.

In extremely rare instances, this may also cause other modules to fail

to configure, without generating additional loss of module faults.

These additional failures may cause communication with the Ethernet

Interface to fail.

The user can recover from either of these cases by turning off power

for at least 5 seconds and then restoring power. This will provide

sufficient "off-time" to ensure that all modules can power up properly.

Modules not reset during firmware

upgrades

The RX7i currently does not reset any other modules in the system

after a firmware upgrade. This may result in Loss of module faults

being generated for smart modules.

Unable to communicate through some

third party serial cards

PACS Systems serial ports do not work with some third party serial

cards.

Incorrect COMMREQ status for invalid

program name

The program name for PACSystems is always "LDPROG1". When

another program name is used in a COMMREQ accessing %L

memory, the error that is generated is 05D5, which is an invalid block

name.
