336A3401AAG11  GE  Central control module Brand new

336A3401AAG11 GE Central control module Brand new

Three isolated serial ports: an RS-485 serial port, an RS-232 serial port, and an RS-232

Ethernet station manager serial port.


Brand: GE                 Model number:336A3401AAG11

Colour:new                  Warranty: 2BPERMATEX

Lead Time:3-day working day   Country of origin: USA

Price: Please contact us         Product weight:0.12kg

hipping Port: China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

336A3401AAG11  GE  Central control module Brand new



• An RX3i Universal Backplane: IC695CHS007, IC695CHS012 or IC695CHS016.

• This PACSystems RX3i CPU. This CPU occupies two backplane slots.

• An RX3i rack-mounted Power Supply Module and compatible power source (AC2

or DC).

• A computer running Proficy Machine Edition (PME) configuration and

programming software. PME Version 8.60 SIM 8 or later supports all features in

this document.

• Ethernet cable for connecting the PME programmer computer to the RX3i CPU.

• Phillip’s head screwdriver.

• Very small slotted screwdriver (1.4mm jeweler’s size).

3.2. Basic Installation Steps:

For startup and configuration of the CPE330, complete the following steps. For full

details on CPE330 operation, refer to the PACSystems RX3i and RX7i CPU Reference

Manual, GFK-2222V or later.

1. Turn power off at the RX3i rack and install the CPE330 in a double-slot which is

CPU-compatible (refer to PACSystems RX3i System Manual, GFK-2314 Chapter 3).

Typically, the CPU is located in the left-most slot pair, or in the pair of slots to the

right of the power supply module.

2. If used, mount the compatible RX3i Energy Pack (IC695ACC402) within 3 feet of

the CPU. The dedicated interconnect cable attaches to the underside of CPE330.

Follow interconnect and grounding instructions in PACSystems RX3i Energy Pack

2 Note: on lightly-loaded racks, use IC695PSA040H or later, or IC695PSA140D or later,

otherwise power-up may be unsuccessful. Alternately, fill out the empty slots in the

rack so as to draw more current.

11 PACSystems* RX3i 1GHz 64MB CPU w/Ethernet Quick Start Guide GFK-2941E
