246B1354G1 GE Module cards in stock

Restriction/Open Issue Description

WinLoader does not display

error when it can't connect

serially with PACS CPU.

WinLoader does not display an error message if it cannot connect to the PACS CPU when

attempting to connect to a PACSystems CPU to perform a firmware upgrade. This occurs if

the cable is physically not connected to the CPU or if the CPU's serial port is not configured for

the same baud as WinLoader. In this case Winloader displays the status trying to connect

followed by waiting for target. To proceed with the upgrade, press the abort button and

correct the cable or baud rate setting.

Operational Notes

Operational Notes

Subject Description

Firmware upgrades using

Slot 1

Firmware upgrades for modules in Slot 1 will only work for CPUs. Modules other than the CPU

need to be in Slot 2 or higher to perform a firmware upgrade.

Multiple calls to SVC_REQ 57

in a single sweep may cause

CPU watchdog timeouts

Multiple calls to SVC_REQ 57 (Logic Driven Write to Nonvolatile Storage) could result in the CPU

tripping the watchdog timer and going to STOP-HALT mode. The number of calls to

SVC_REQ 57 that can be made requires consideration of many variables, what the software

watchdog timeout value is, how much data is being written, how long the sweep is, age of

nonvolatile storage (flash), etc. If the application attempts to write to flash too frequently, the

CPU could experience a watchdog timeout while waiting for a preceding write operation to

complete.

The Logic Driven Read/Write to Flash service requests are not intended for high frequency

use. GE Intelligent Platforms recommends limiting the number of calls to SVC_REQ 57 to one

call per sweep to avoid a potential watchdog timeout and the resulting transition to StopHalt.

Error response 1 is no longer

returned for Modbus RTU

requests with invalid or

undefined function codes.

Prior to release 6.70 for the RX3i, the Modbus RTU slave protocol would return an Invalid

Function Code error response (1) upon receipt of a request with an invalid or undefined

function code. Starting with release 6.70, the Modbus RTU slave ignores requests with an

invalid or undefined function code, and no response is sent
